SCP-AMU912-010-06H
N M
ETWORK ENU
The Network Menu provides access to all available and connected AMU-912s on the 10Base-2 Local Area Network
(LAN). Refer to Table 19
Sub-Menu
Options
MultiShelf Access
Connection Summary
Local Summary
Inband Traffic Summary
38
O
PTIONS
for sub-menu options and descriptions.

Table 19. Network Menu Options

View all accessible Management Units (AMU-912s/PMU-712s) existing on the
10Base-2 LAN
View all incoming MultiShelf connections (maximum of 3)
View the Local Card Summary for the AMU-912 (includes card identification
information, port session locations and states, and alarm activity)
View frame counts for inband traffic on individual network DS1 ports
Sub-Menu
Descriptions
ADC Telecommunications, Inc.
July 19, 2004
