SCP-AMU912-010-06H
MSLAN Connection to Router – Different Segment, Unrestricted Route
In the set-up illustrated in
AMU-912 to respond to packets not originating on the local segment
configuring a gateway router to which the AMU-912 can direct its reply packets. You can access these values from
the CONFIG — IP INFO on page
Route and Default Route Mask fields must have the value of 000.000.000.000.
VT-100 Terminal

Figure 12. MSLAN Connection with Different Segment, Unrestricted Route Model

22
Figure 12, clients attempting to connect through the TELNET protocol must configure the
72. The gateway IP address must be accessible from the MSLAN, and the Default
TELNET
Client 1
10Base-T
Shelf 1
50Ω Terminator
ˇ
(Table 14 on page
TELNET
TELNET
Client 2 Client 3
Router
Shelf A
10Base-2 Ethernet
July 19, 2004
23). This is accomplished by
50Ω Terminator
ADC Telecommunications, Inc.
