Each environmental alarm can be sent via specific bit locations in the datalink. Refer to
alarm bit values. Refer to
Value
NOT REPORTED
SYS1-PWRMISC
SYS1-MN
SYS1-MJ
SYS2-PWRMISC*
SYS2-MN*
SYS2-MJ*
COM-PWRMISC*
COM-MN*
COM-MJ*
* DS1 5 (System 2 SHELF A) must be up and operating in TR-08 mode for these alarms to work correctly.
ADC Telecommunications, Inc.
Table 30
for alarm defaults.
Table 29. Environmental Alarm TR-08 Bit Positions
Not reported
Reported via the system 1 PWR/MISC bit
Reported via the system 1 MN bit
Reported via the system 1 MJ bit
Reported via the system 2 PWR/MISC bit
Reported via the system 2 MN bit
Reported via the system 2 MJ bit
Reported via the system 1 and system 2 PWR/MISC bit
Reported via the system 1 and system 2 MN bit
Reported via the system 1 and system 2 MJ bit
Table 30. Environmental Alarm Defaults
Alarms
Environmental #1
Environmental #2
Environmental #3
Environmental #4
* Defaults to COM-MN in Field Shelf
Table 29
Description
Default
SYS1-PWRMISC
SYS2-PWRMISC*
COM-MN
COM-MJ
SCP-AMU912-010-06H
for a list of possible
93
