SCP-AMU912-010-06H
MSLAN Connection to Router – Different Segment, Restricted Route
In the set-up shown in Figure
AMU-912 to respond to packets not originating on the local segment but confine the accessibility of the MSLAN to a
particular network (CONFIG — IP INFO on page
• Configure a gateway router to which the AMU-912 can direct its reply packets. The gateway IP address must be
accessible from the MSLAN.
• Configure the Default Route and Default Route Mask fields to the values of the external Network to which
accessibility is granted.
VT-100 Terminal

Figure 13. MSLAN Connection with Different Segment, Restricted Route Model

24
13, clients attempting to connect by means of the TELNET protocol must configure the
72). Refer to
TELNET
Client 1
10Base-T
Shelf 1
50Ω Terminator
ˇ
Table 15 on page 25.
TELNET
TELNET
Client 2
Client 3
Router
Shelf A
10Base-2 Ethernet
July 19, 2004
50Ω Terminator
ADC Telecommunications, Inc.
