S M
ERIAL ANAGEMENT INTERFACES
An RS-232 serial interface is provided on the front of the AMU-912 and meets the following specifications:
• compliant with EIA-RS-232
• full duplex, serial, asynchronous format
• supports baud rate:
– 1200
– 2400
– 4800
– 9600
– 19200
– 38400
– 57600
– 115200
• configured as DCE, supporting Transmit, Receive, DTR, and DSR signals
• 9-pin DB type connector
An RS-232 serial interface is provided on the shelf backplane and meets the following specifications:
• compliant with EIA-RS-232
• full duplex, serial, asynchronous format
• supports baud rate:
– 1200
– 2400
– 4800
– 9600
– 19200
– 38400
– 57600
– 115200
• configured as DTE, supporting Transmit, Receive, DTR, and CD signals
• 25-pin DB type connector
