Table 14. Example of Connection to Router – Different Segment, Unrestricted Route
Entity IP Address
Shelf A 172.17.0.3
AMU-912
TELNET 172.17.20.9
Client 1
TELNET 172.10.20.9
Client 2
TELNET 128.33.20.9
Client 3
ADC Telecommunications, Inc.
Subnet Gateway IP
Mask Address
255.255.0.0 172.17.x.x
255.255.0.0 172.17.0.1
255.255.0.0 172.10.0.1
255.255.0.0 0.0.0.0
Default
Default Route
Route Mask
0.0.0.0 0.0.0.0
SCP-AMU912-010-06H
Results
Defines that the AMU-912
exists on the 172.17.xxx.xxx
network and responds only to
requests originating from this
network. Thus, the following
clients may or may not
communicate with the the
target AMU-912.
Able to communicate with
target Shelf A AMU-912
Able to communicate with
target Shelf A AMU-912
(provided that 172.10.xxx.xxx
is accessible by the gateway
device)
Unable to communicate with
target Shelf A AMU-912
(provided that 128.33.xxx.xxx
is not accessible by the
gateway device)
Since no gateway is specified,
the client is not able to
communicate unless
connected to a Hub/Switch
instead of a Router
