C O
ONNECTING
The AMU-912 supports up to three simultaneous TELNET connections. You can use either the SNMP or the
Screens Interface to manage the AMU-912. The logical connection over TELNET provides the same functionality
and interface as a locally connected craft port. However, only TELNET clients fully supporting the VT-100 emula-
tion can adequately provide access to the Screens Interface. There exists a number of possible physical configura-
tions to access one or more AMU-912s and each is described below.

TELNET Client

The AMU-912 supports all TELNET client application software complying with (RFC854) "The TELNET Protocol"
standard. Additionally, TELNET client applications providing full support for the VT-100 standard may be used to
remotely access the Screens and Screens MultiShelf interfaces. Known VT-100 compliant TELNET client
applications are:
• ProComm Plus 3.x, 4.x
• Reflection X 7.x
Packages that do not provide the full VT-100 emulation have unpredictable display results. The AMU-912 TELNET
Server supports the TELNET negotiation options:
• Suppress Go Ahead
• Will Echo

MS LAN

Accessibility of the Multishelf Local Area Network (MSLAN) is dependent upon its physical connections. An MSLAN
can support from one to a maximum or 24 AMU-912s on a single segment. There are two different methods for
connecting one or more AMU-912s to a MSLAN:
• The preferred/recommended method to connect an MSLAN consists of one or more shelves connected by
means of 10Base-2 cabling and connectors on their respective backplanes. Each end of the daisy-chained LAN
must be terminated using 50 Ω BNC-terminations.
• A second/alternative method to connect an MSLAN consists of one or more shelves connected to a network by
means of 10Base-T cabling to the front panel of the AMU-912 in a star configuration. In this method, the
10Base-2 connections on the backplane must NOT be used.
To remotely connect with the MSLAN, at least one AMU-912 on the segment must have a 10Base-T connection to a
user's network. With this type of connection, the AMU-912 must have a correctly configured IP Address and Subnet
Mask. You can access these values from
assigned for IP connectivity.
An MSLAN must NEVER be connected to a network via both 10Base-T and 10Base-2. The only
WARNING
recommended method for connecting the MSLAN to the user's network is via a 10Base-T
connection.
Refer to the following four distinct topographies described in the following sections. These topographies can be
created to allow or restrict remote access to an MSLAN.
ADC Telecommunications, Inc.
TELNET
VER
CONFIG — IP INFO on page
SCP-AMU912-010-06H
72. Both of these values must be correctly
