Table 16. Shdsl-A And Shdsl-B Alarm Thresholds - ADC PG-FlexPlus ARL-942 Manual

January 6, 2003
Alarms
SHDSL ES 15 MIN
SHDSL ES 24 HOUR
SHDSL UAS 15 MIN
SHDSL UAS 24 HR
SHDSL LOW MARGIN 0 to 10
ADC Telecommunications, Inc.

Table 16. SHDSL-A and SHDSL-B Alarm Thresholds

Value
0 to 900
Threshold value for the SHDSL 15 minute interval
ES alarm
0 to 86,400
Threshold value for the SHDSL 24 hour interval
ES alarm
0 to 900
Threshold value for the SHDSL 15 minute inter-
val UAS alarm
0 to 86,400
Threshold value for the SHDSL 24 hour interval
UAS alarm
Threshold value at which alarm is set active if
margin drops equal to or less than this number
Description
SCP-ARL942-010-02H
COLU Alarm RT Alarm
Threshold Threshold
Default Default
10 10
170 170
240 240
600 600
01 01
69
