ALARMS — ADSL-A Downstream History
This screen displays the alarm type, current status, counts and the first and last occurrences. Refer to
page 81 for ADSL Alarms.
Under the Current alarm column, if the word ACTIVE displays, the alarm is currently active. If the status OK
displays, the alarm is not present. If the word SUPPRESSED displays, the alarm is active but suppressed.
Clearing the system alarm history does not clear the current alarms. If there is an active alarm, then the
count is set to 1 and the value in the LAST Cleared date and time field is set to the FIRST date and time field.
ALARMS — ADSL-A Downstream History
Step
1
At the Main Menu screen, select ALARMS. Press
following screen appears.
ADC Telecommunications, Inc.
Action
to choose ADSL-A Downstream History. The
↓
SCP-ARL942-010-02H
Table 20 on
