SCP-ARL942-010-02H
LED
PWR Green
SHDSL Green
FAULT Red
ADSL # Green
(# = 1 – 8)
8

Table 3. ARL-942 Front Panel LEDs

Color State
On ARL-942 is receiving power from the ALU-935
Off ARL-942 is not receiving power from the ALU-935
On SHDSL is in sync between the ARL-942 and the ALU-935
Flashing SHDSL is in sync between the ARL-942 and the ALU-935, but the
(Fast) margin is below the threshold
Flashing SHDSL is attempting to sync
(Slow)
Off SHDSL does not detect a signal from the ALU-935
On An internal fault has been detected in the ARL-942
Off No internal fault has been detected in the ARL-942
On ADSL is in sync
Flashing ADSL is in sync between the ARL-942 and the ALU-935 and the
(Fast) margin is below the threshold
Flashing ADSL is idle or attempting to sync
(Slow)
Off LEDs are in power save mode. Press LED REFRESH to see
status.
