Initialize And Power Up The Arl-942; Administration - ADC PG-FlexPlus ARL-942 Manual

SCP-ARL942-010-02H
I P
NITIALIZE AND OWER
After installing the ARL-942, the following events occur:
• All LEDs briefly blink on and then off, with the exception of the PWR LED that remains On.
• SHDSL LED blinks until it is fully synchronized (up to a few minutes), then remains On.
• All ADSL LEDs blink (until sync), then stays On for a few minutes, then extinguishes.
• Fault LED does not come On unless a fault is detected
• Beyond this time, the LED REFRESH button must be pressed to view the ADSL LED status. These LEDs
automatically extinguish after two minutes.
A
DMINISTRATION
Refer to the proper Management Unit Technical Practice for detailed Administration instructions.
For example:
1. Provision your PC/Laptop running Windows HyperTerminal or PROCOMM, etc. to the following terminal settings:
8 data bits
1 stop bit
no parity
VT-100 emulation
9600 baud
2. Connect the DB-9 cable between the RS-232 port on the front of the Management Unit and the PC/Laptop
serial port.
3. Press several times until the Main Menu appears.
ENTER
10
U ARL-942
P THE
(Table 22 on page 98).
