ADC PG-FlexPlus ARL-942 Manual page 54

SCP-ARL942-010-02H
PERFORMANCE — ADSL-A 3 Day History (Continued)
Step
2
Press . The following screen appears.
ENTER
The current day performance information shows the performance since the previous midnight. At
midnight of every day, the current day performance history is moved to the previous day's history and
the current day performance information is cleared. The status of the count is shown as:
• ADJ (Adjusted):
• COM (Complete):
• PAR (Partial):
• UNA (Unavailable): Data has not been collected for this interval or has been reset during a previous
The following actions can be taken:
a. To clear the ADSL 3 Day status, select Clear ADSL 3 Day History button.
b. To retain the existing ADSL 3 Day History, press
42
Action
Time or date has been changed or the history cleared on the system during this
interval
Data is saved in the history register for this interval
Data is being collected for this interval
time interval
.
ESC
ADC Telecommunications, Inc.
January 6, 2003
