Log On The ARL-942 Through the Management Unit

This screen logs the user into the ARL-942 by going through the Management Unit (PMU-712/AMU-912). The
example below shows how to log into the PMU-712.
The factory-default password is password#1.
If the password has been changed and the new password is not known, contact ADC Technical Support
while at the terminal. Technical Support will provide a temporary password based on the Access Key
number displayed on the Logon screen.
Log On The ARL-942 Through the Management Unit
Step
1
After connecting a VT-100 terminal to the PMU-712, press
autobaud feature. The Login Password screen appears.
2 If an invalid Password is entered, the Login screen is redisplayed with the message Invalid
Password...Try Again:.
ADC Telecommunications, Inc.
Action
several times to start the
SPACEBAR
SCP-ARL942-010-02H
13
