Alarms - System History - ADC PG-FlexPlus ARL-942 Manual

January 6, 2003
ALARMS — System History
This screen displays the alarm type, current status, counts and the first and last occurrences. The alarms and
default values are defined in
Under the Current alarm column, if the word ACTIVE displays, the alarm is currently active. If the status OK
displays, the alarm is not present. If the word SUPPRESSED displays, the alarm is active but suppressed.
Clearing the system alarm history does not clear the current alarms. If there is an active alarm, then the
count is set to 1 and the value in the LAST Cleared date and time field is set to the FIRST date and time field.
ALARMS — System History
Step
1
At the Main Menu screen, select ALARMS. Press
appears.
ADC Telecommunications, Inc.
Table 15 on page 66.
Action
to choose System History. The following screen
↓
SCP-ARL942-010-02H
47
