PERFORMANCE — ADSL-A 3 Day History
This screen displays the last 3 days of performance statistics of the ADSL link between the RT and Modem. This
information includes ES, SES and UAS counts and the validity of the values for the Edge IAD ADSL facility or
selected Edge RAM ADSL facility.
If there are active alarms associated with the current ADSL-A 3 day history information, those alarms
become inactive when the ADSL-A 3 day history status performance history is cleared and reactivates once
the threshold has been crossed.
PERFORMANCE — ADSL-A 3 Day History
Step
1
At the Main Menu screen, select PERFORMANCE. Press
following screen appears.
ADC Telecommunications, Inc.
Action
to choose ADSL-A 3 Day History. The
↓
SCP-ARL942-010-02H
41
