SCP-ARL942-010-02H
PERFORMANCE — ADSL-A 15 Minute Status
This screen displays the current 15 minute performance statistics of the ADSL link between the RT and Modem.
This information includes ES, SES and UAS counts and the validity of the values for the Edge IAD ADSL facility or
selected Edge RAM ADSL facility.
If there are active alarms associated with the current ADSL-A 15 minute status information, those alarms
become inactive when the ADSL-A 15-Min status performance history is cleared and reactivates once the
threshold has been crossed.
PERFORMANCE — ADSL-A 15 Minute Status
Step
1
At the Main Menu screen, select PERFORMANCE. Press
following screen appears.
38
Action
to choose ADSL-A 15 Min Status. The
↓
