Evaluation Board User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 1.
Qty Reference Designator
2 C1, C2
1 C3
3 C4, C5, C11
1 C6
1 C12
4 C7, C8, C9, C10
1 D1
1 JP1
2 JP2, JP3
1 J1
1 J2
2 J3, J11
1 J4
6 J5, J6, J7, J8 ,J9, J10
1 R1
1 R2
3 R5, R6, R7
4 R8, R13, R14, R15
2 R9, R12
3 R10, R11, R16
1 R17
1 R18
20 TP1 to TP20
1 U1
1 U2
1 U3A
Description
Capacitors, MLCC, 1 µF, 10 V, 0805, X7R
Capacitor, MLCC, 10 µF, 25 V, 0805, X5R
Capacitors, MLCC, 22 µF, 6.3 V, 1206, X5R
Capacitor, MLCC, 100 nF, 16 V, 0402, X7R
Capacitor, MLCC, 10 nF, 16 V, 0402, X7R
Capacitors, size 1206
Red LED 2.2 mm × 1.4 mm
Connector header, 3 pins × 1 pin
Connector headers, 10 pins × 1 pin
MKDS 1, 5/2-terminal block, PCB, 5 mm, 2-way
Terminal block PCB connector, 4 position
Connector headers, 3 pins × 1 pin
USB Micro AB connector receptacle
Connector headers, 2 pins × 1 pin
Resistor, 56 kΩ, 1%, 0805, SMD
Resistor, 100 kΩ, 1%, 0805, SMD
Resistors, 0805, SMD, no assembly
Resistors, 1.5 kΩ, 1%, 0805, SMD
Resistors, 10 kΩ, 1%, 0805, SMD
Resistors, 0 Ω, 1%, 0805, SMD
Resistor, 470 Ω, 1%, 0805, SMD
Resistor, 0.150 Ω, 1%, 0805, SMD
Test point, test header, 1.0 mm hole
ADP1720 50 mA high voltage, micropower linear
regulator, 8-lead MSOP
2
ADP5061 tiny I C programmable linear battery charger
with power path and USB mode compatibility
2
8-bit I C-bus I/O port with reset
Rev. 0 | Page 11 of 12
Manufacturer/Vendor Vendor Number
Murata GRM21BR71A105KA01
Murata GRM21BR61E106MA73
Murata GRM31CR60J226ME19
Murata GRM155R71C104KA88
Murata GRM15XR71C103KA86
Not assembled Not assembled
Toshiba or equivalent TLRF1060(T18)
Sullins Electronics PEC36SAAN
Not assembled Not assembled
Phoenix Contact or MKDS 1, 5/2
equivalent
Tyco Electronics 282836-4
Sullins Electronics PEC36SAAN
Molex 47590-0001
Sullins Electronics PEC36SAAN
Vishay or equivalent CRCW080556K0FKEA
Panasonic ERJ-6ENF1003V
Not applicable Not applicable
Vishay or equivalent CRCW08051K50FKEA
Vishay or equivalent CRCW080510K0FKEA
Vishay or equivalent CRCW08050000Z0EA
Vishay or equivalent CRCW0805470RFKEA
Rohm MCR10EZHFLR150
Vero Technologies 20-2137
Analog Devices, Inc. ADP1720ARMZ-R7
Analog Devices, Inc. ADP5061
NXP PCA9557PW, 112
UG-467
