CHARACTERISTICS:

The HD67818 is a PROFINET / KNX Converter.
It has the following characteristics:
Up to 1440 bytes in reading and 1440 bytes in writing;
Triple isolation between KNX - Power Supply, KNX – Ethernet, Power Supply - Ethernet.
Two-directional information between KNX bus and PROFINET bus;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67818 software on your PC in order to perform the following:
Define the parameter of PROFINET line;
Define the parameter of KNX line;
Define the KNX messages that the Converter can accept;
Define the KNX frames that the Converter sends trough the KNX line;
Define the map of KNX byte that must be written in the PROFINET side;
Define the map of which PROFINET I/O must be written in KNX messages;
Update the device.
