Replacing the Daughter Board and the Daughter Board Clip
FIGURE 3-26
5. Connect the LED cable to the LED clip.
J1
Connecting the LED Cable to the LED Clip
FIGURE 3-27
6. Install the power supply, and tighten the corner screws and lock box.
7. Install the hard drives.
8. Install the drive access panel, and lock it.
9. Install the power cord to the power supply.
10. Connect the I/O cables to their connectors on the back panel.
The MultiPack-FC is now ready for use.
