1.3

Types of Connection

1.3.1

Box IDs

Box IDs 1–15 are available. Sun suggests that you use box IDs 1 and 2 for daisy-
chained units. Box IDs are set on the back panel with a switch (FIGURE 1-2). When
connecting multiple units to a host system be sure that each unit has a unique box
ID.
1.3.2

Target IDs

Note – For drive slot numbering, see FIGURE 2-3 and FIGURE 2-4.
The formula for target IDs (target addresses) is:
Box ID * 8 + Slot ID = Target ID
TABLE 1-1
Box ID
1
2
1-6 Sun StorEdge MultiPack-FC Installation, Operation, and Service Manual • August 2000
Target IDs
Drive Slot Target ID
0 t8
1 t9
2 t10
3 t11
4 t12
5 t13
0 t16
1 t17
2 t18
3 t19
4 t20
5 t21
