Sun Microsystems StorEdge MultiPack-FC Installation, Operation And Service Manual page 76

FIGURE 3-23
5. Remove all the drives from the drive cage.
6. Remove the drive cage (FIGURE 3-24). There are six screws to remove:
Two screws on the bottom of the chassis
Two screws on the back of the chassis near the I/O connectors
(FIGURE 3-24, A and B)
Two screws by the left side of the drive cage
3-26 Sun StorEdge MultiPack-FC Installation, Operation, and Service Manual • August 2000
Removing the Daughter Board Clip and the Daughter Board
