2.1.1

Power LED

TABLE 2-1
Display
Green
Off
2.1.2

Drive LEDs

TABLE 2-2
Display
Green, Steady
Green, Flashing
Amber, Steady
Off
2.2

Configuring Drives

Each Sun StorEdge MultiPack-FC unit is configured with a minimum of two and a
maximum of six hard drives that are 25.4-mm (1.0-in.) in height (FIGURE 2-2).
Power LED Displays
Status
Power supply turned on, normal
Power supply off
Drive LED Displays
Status
Drive present, inactive
Drive present, active
Drive present, failed
Drive absent
Chapter 2 Operation 2-3
