1.3.6
Cabling Applications
Key:
HSSDC = High-speed serial data connection
GBIC = Gigabit interface converter
OOGBIC = Optional optical gigabit
interface converter
FIGURE 1-6
Key:
HSSDC = High-speed serial data connection
GBIC = Gigabit interface converter
OC = Optical Connector
OOGBIC = Optional optical gigabit
interface converter
FIGURE 1-7
1-8
Sun StorEdge MultiPack-FC Installation, Operation, and Service Manual • August 2000
HSSDC
Host
Copper cable with
HSSDC connectors
on both ends
Optional
optical
cable
3.0m Copper Cable With HSSDC Connectors for Host Connection
Copper cable with
HSSDC connectors
on both ends
OC
Host adapter
3.0m Copper Cable With HSSDC Connectors for Daisy-Chain Connection
HSSDC
OOGBIC
HSSDC
OOGBIC
HSSDC
OOGBIC
Optional
optical
cable
HSSDC
MultiPack-FC
MultiPack-FC
MultiPack-FC
MultiPack-FC
