Hardware Configuration
Guide
Sun Microsystems, Inc.
901 San Antonio Road
Palo Alto, CA 94303-4900 USA
650 960-1300
Fax 650 969-9131
Part No. 805-4981-11
September 1998, Revision A
Send comments about this document to: docfeedback@sun.com
