Setting The Box Id; Section 2.3 "Setting The Box Id - Sun Microsystems StorEdge MultiPack-FC Installation, Operation And Service Manual

Three-drive configuration
Five-drive configuration
FIGURE 2-4
2.3

Setting the Box ID

On the back of the MultiPack-FC chassis is a box identification (ID) switch
(FIGURE 2-5). The box ID number is set at 1 at the factory.
2-6 Sun StorEdge MultiPack-FC Installation, Operation, and Service Manual • August 2000
(two drives plus one additional drive)
(four drives plus one additional drive)
Adding Drives to Standard Configurations
D0 D1
D2
D0 D1
D2 D3
D4
