Start M4 Xxl/ M5 Comfort - Otto Bock Start M1 Intro Service Manual

Maintenance Plan
for regular service
Item
Component (group)
Serial no.:
M4 XXL M5 Comfort
4 A Frame
Frame accessories
4 B Footrests
4 C Seat
4 D Back / push handle
Back accessories
4 E Side panel
4 F Caster
4 G Rear wheel
Rear wheel accessories
4 H Brake / wheel lock
Brake / wheel lock accessories
4 S Accessories
Do the settings of the
wheelchair comply with the
user's requirements?
Maintenance performed by: on:

Start M4 XXL/ M5 Comfort

- Lightweight Wheelchair -
.)
Function / setting
(see 647G324 Instructions for Use)
- Frame
- Central unit
- Anti-tipper
- Transport wheels
- Crutch holder
- Flip-up mechanism
- Lower leg length setting
- Angle adjustment
- Crossbrace
- Seat upholstery
- Seat cushion
- Back upholstery
- Back tubes
- Angle adjustment (M5)
- Fold-down mechanism (M5)
- Push handles
- Side thoracic support (M5)
- Stabilization bar (M4)
- Height setting
- Swivel mechanism
- Tires (wear)
- Air pressure
- Caster journal angle
- Screw connection of the caster
journal bearing
- Running behavior of the wheels
- Swiveling of the wheel forks
- Tires (wear)
- Air pressure
- Running behavior of the wheels
- Spokes
- Push rings
- Quick-release axles
- Wheel camber (M5)
- Rear wheel adapter
- Drum brake
- Spoke protectors
- Brake function
- Wheel lock lever extension
- Tray
- Lap belt
