4.G - Rear Wheel
Replacing the tires
For replacing the casing, inner tube and rim band,
please observe the information given in the instruc-
tions for use manual.
Attention: Replace the casing if it is bald or shows
cracking or other damage.
Replacing the push rings
Loosen and remove the screw connection of the
push rings with the rim and remove the push ring.
For reassembly, please proceed in reverse order.
24
Retightening the spokes and adjusting to a radial
excursion with a maximum of ±1 mm
Check to see if spokes are broken and that they are
still tight by trying to move them.
Adjustment of the radial excursion requires special
devices and expertise. Please have the adjustment
carried out by a bicycle workshop.
Setting the quick-release axle
The quick-release axle should be set so the wheel is
fully engaged but has the minimum amount of lateral
axle play. Using a wrench hold the inner end of the axle
still, whilst the outer nut of the axle is adjusted so as to
give the correct lateral axle distance.
Please also observe the information regarding main-
tenance, cleaning and care given in the instructions
for use manual.
