IN CASE OF EMERGENCY
When your ship requires assistance, contact other
ships and the Coast Guard by sending a distress call
using digital selective calling on 2187.5 kHz.
When immediate help is needed
q Push and hold [DISTRESS] for 5 sec. until the
short beeps become one long beep, to send the
distress call.
w After 2182 kHz is automatically selected (after an
acknowledgement call is received), push and hold
the PTT switch on the microphone and send the
following information.
1. "MAY DAY, MAY DAY, MAY DAY."
2. "THIS IS . . . . . . . . . " (name of ship)
3. "LOCATED AT . . . . " (ship's position)
4. Give the reason for the distress call.
5. Explain what assistance you need.
6. Give additional information:
• Ship type
• Ship length
• Ship color
• Number of people on-board
TABLE OF CONTENTS
FOREWORD................................................i
IMPORTANT .............................................. i
EXPLICIT DEFINITIONS ........................... i
PRECAUTIONS ......................................... i
IN CASE OF EMERGENCY ......................ii
TABLE OF CONTENTS ............................ ii
QUICK REFERENCE ............................. I-V
I How to set a Channel/Group .............. I
I Audio output/squelch adjustment ...... II
I Receiving a DSC............................... IV
I Transmitting a distress call................ IV
............................................................... 1
2 PANEL DESCRIPTION .................... 2-7
I Front panel- Controller .................... 2
I Front panel- Main unit ...................... 4
I Rear panel- Main unit ...................... 5
I Microphone (HM-135) ....................... 5
I LCD screen ....................................... 6
3 SETTING A CHANNEL .................... 8-9
I Selecting a channel ........................... 8
4 RECEIVE AND TRANSMIT .......... 10-13
I Functions for transmit ...................... 10
I Functions for receive ....................... 11
I CW operation .................................. 12
I FSK operation ................................. 13
..................................................... 14
When potential problems exist
q Push [DSC] to select DSC watch mode, if neces-
sary.
w Push [MODE
to select "All ships" then push [ENT].
e Follow the guidance displayed on the LCD (bottom
line), to set up the category, traffic frequency and
calling frequency with [CH], [ENT] and keypad.
r Push and hold [CANCEL/CALL] for 1 sec. until the
short beeps become one long beep.
t After an acknowledgement call is received, trans-
mit the appropriate information using voice.
• DSC equipped ships may monitor your transmission.
6 DSC PREPARATION ................... 15-16
I MMSI code programming ................ 15
I Position and time programming ....... 16
7 CALL PROCEDURE .................... 17-36
I Distress call ..................................... 17
I Distress call to ships ........................ 21
I Urgency call ..................................... 24
I Safety call ........................................ 28
I Routine call ...................................... 32
I Group call ........................................ 34
I Position request call ........................ 35
I Test call ........................................... 36
8 WHEN RECEIVING A CALL ........ 37-42
I To receive a DSC call ...................... 37
I Received information ....................... 38
I Deleting a memory .......................... 38
I Distress call ..................................... 39
I Distress relay call ............................ 39
I All ships call ..................................... 40
I Group call ........................................ 40
I Geographical area call .................... 40
I Individual call ................................... 41
I Position request call ........................ 42
9 MEMORY OPERATION ..................... 43
I Memory description ......................... 43
I Memory writing ................................ 43
......................................................... 43
10 DSC MENU OPERATION ............ 44-46
I General ............................................ 44
I ID input ............................................ 44
] to select DSC menu, rotate [CH]
SET
I Frequency input ............................... 45
I Verifying self-ID ............................... 46
I Memory reading/deleting ................. 46
11 E-MAIL OPERATION ......................... 47
I General ............................................ 47
I Operation ......................................... 47
12 SET MODE ................................... 48-52
I Quick set mode ............................... 48
I Initial set mode ................................ 49
....................................................... 53-62
I Supplied accessories ...................... 53
I Front panel connections ...................53
I Rear panel connections ................... 54
I Ground connection .......................... 55
I Power source .................................. 55
I Antenna ........................................... 56
I Mounting .......................................... 57
I Using the optional MB-75 ................ 58
I Transceiver dimensions ................... 59
I Fuse replacement ............................ 60
I Connector information ..................... 61
CONSIDERATIONS ..................... 63-65
15 SPECIFICATIONS .............................. 66
16 TEMPLATE .................................. 67-70
I Remote controller (RC-25) .............. 67
I Speaker (SP-24) .............................. 69
17 OPTIONS ........................................... 71
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
ii
