SET COMMUNICATION:

This section define the fundamental communication parameters of two buses, SNMP and CANopen.
By Pressing the "Set Communication" button from the main window for SW67156 (Fig. 2) the window "Set
Communication" appears (Fig. 3).
The window is divided in two sections, one for the SNMP and the other for the CANopen.
The means of the fields for "SNMP" are:
In the field "IP ADDRESS" the IP address of SNMP side of the converter is defined;
In the field "SUBNET Mask" the SubNet Mask of SNMP side of the converter is defined;
In the field "GATEWAY" the default gateway of the network is defined. This feature can be enabled or
disabled pressing the Check Box field. This feature is used for going out of the net;
In the field "SNMP Name of
In the field "Contact" the contact for SNMP Agent station is defined;
In the field "Location" the location for SNMP Agent station is defined;
In the field "Version" the version of SNMP is defined;
If SNMP V3 is used, the following fields must be filled:
In the field "User" the user for the SNMP authentication is defined;
o
In the field "Security
o
In the field "Authority" the password for the SNMP authentication is defined;
o
In the field "Authority
o
In the field "Privacy" the password for Privacy authentication is defined;
o
In the field "Privacy
o
The means of the fields for the "CAN" section are:
In the field "Device ID" the ID of the CANopen side is defined;
In the field "Baudrate" the data rate of the CANopen line is defined;
In the field "Set Operational State at
the board starts in Operational State, else it starts in Pre-Operational;
ADFweb.com Srl – IT31010 – Mareno – Treviso
Station" the name for SNMP Agent station is defined;
Level" the type of security used is defined;
Mode" the mode used for the authentication is defined;
Mode" the mode used for Privacy is defined;
Start-Up" the state of the CANopen is defined. I.e. If it is checked
User Manual SNMP Agent / CANopen
Document code: MN67156_ENG
Figure 3: "Set Communication" window
