Dip Switch Setting

VHE02EIPT
Switch Function
SW1 ON Video Firmware update
SW2 ON Control Firmware update
SW3 Reserve
SW4 Reserve
VHE02EIPR
Switch Function
SW1 ON Video Firmware update
SW2 Reserve
Cable
Link cable recommend use high quality CAT5e、CAT6、CAT6a、CAT7 UTP / STP or FTP cable. Poor quality
cable or network connection or improper construction will cause unstable connection, video or sound
disruptions, picture noise appears.
Distance chart by different cable
Cable Type
CAT5e / CAT6
CAT6a / CAT7
CAT5e / CAT6
CAT6a / CAT7
If connection through the wall socket, the cable length must less 5 meters between HDMI
extender and wall jack, as below drawing:
VHE02EIPT
5M
3
Range Supported Video
60M
1080p 60Hz 12bit
70M
35M
1080p 60Hz 16bit
Up to 4096x2160@30Hz 4:4:4(9Gbps)
40M
Wall Jack
OFF
RS232 Extender
OFF
OFF RS232 Extender
70M(Max)
MAX 70 米
User Manual
VHE02EIP
VHE02EIPR
Wall Jack
5M
