- Page 1 VGA Extender User Manual Model : VE01P Passive VGA CAT5e Extender Smart Cabling & Transmission Corp. V1.0...
-
Page 2: Installation View
Introduction VE01P is a VGA extender designed to use a cost-effective 4 pairs CAT5e UTP cable to carry the signal for a long distance, with the resolution up to 1920 x 1080@60Hz, replacing costly and bulky VGA cable. It's an Ideal solution for classrooms, lecture halls, retail store, PC-training systems, and demo systems for tradeshows. - Page 3 User Manual VE01P Transmission Distance Chart Max. Distance via CAT5e Cable 800x600 pixels (60Hz) 100M 1024x768 pixels (60Hz) 1280x1024 pixels (60Hz) 1920x1080 pixels(60Hz) Cable Recommended CAT5e UTP/STP or CAT6 UTP cable. There are some monitor models with very high demand at sync-sensitive, it is recommended to use STP (shielding twisted pair) cable instead of UTP (unshielded twisted pair) cable.
- Page 4 User Manual VE01P Slide Switch Setting VE01PT Sync Mode Select ← Mode 1 → Mode 2 For new type monitors, such as LCD Monitor over 17”, it is recommended setting at Mode 1 for the best transmission stability. If the picture is not normal, please switch to Mode 2.
- Page 5 User Manual VE01P Troubleshooting of picture problem No picture display Check Link cable. Check DIP switch setting. Check VGA cable connection. Change the resolution or frequency. Change UTP to STP cable. Picture not stable or intermittent disappearing ...
-
Page 6: Specification
User Manual VE01P Specification ITEM NO. VE01PT VE01PR Support Compliance Max. Video Resolution 1920 x 1200px Max. Transmission Distance 100M over CAT5/ CAT5e/ CAT6/ STP or UTP Cable Video Bandwidth 300kHz Insertion Loss Less than 3dB Video Return Loss -15dB Ports &...
