Button Function:

FORCE SELECT
Short Press
Long Press over 2
seconds
Dip Switch Setting：
VHE02EIPT
Switch
SW1 ON
SW2 ON
SW3
SW4
VHE02EIPR
Switch
SW1 ON
SW2
Cable:
Link cable recommend use high quality Cat.5e 、 Cat.6 、 Cat.6a 、 Cat.7 UTP / STP or FTP
cable. Poor quality cable or network connection or improper construction will cause
unstable connection, video or sound disruptions, picture noise appears.
Distance chart by different cable:
Cable Type
CAT5e / CAT6
CAT6a / CAT7
CAT5e / CAT6
CAT6a / CAT7
If connection through the wall socket, the cable length must less 5 meters between HDMI
extender and wall jack, as below drawing:
VHE02EIPT
5M
Manual Switch Mode: HDMI or VGA Input Selection
Auto Switch Mode: Auto Switch HDMI or VGA Input
Long Press: HDMI and VGA LED flash at same time that mean the
auto switch mode setting completed.
Under Auto Switch Mode: HDMI and VGA connect simultaneously,
VGA will be the priority.
Control Firmware
update
Video Firmware
update
Video Firmware
update
Range
60M
70M
35M
Up to 4096x2160@30Hz 4:4:4(9Gbps)
40M
70M(Max)
Wall Jack
Function
Function
OFF
RS232 Extender
OFF
Reserve
Reserve
Function
OFF RS232 Extender
Reserve
Supported Video
1080p 60Hz 12bit
1080p 60Hz 16bit
MAX 70 米
VHE02EIPR
Wall Jack
5M
