Chapter 4: BIOS Setup

BIOS Setup Utility

Once you enter the AMI BIOS Setup Utility, the Main Menu will appear on
the screen. The main menu allows you to select from several setup functions
and one exit. Use arrow keys to select among the items and press
accept or enter the submenu.

Main

The Main menu is the first screen that you will see when you enter the BIOS
Setup Utility.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset Boot
BIOS Information
BIOS Vendor American Megatrends
Core Version 4.6.5.4
Compliancy UEFI 2.3.1; PI 1.2
Project Version S241-007 x64
Build Date and Time 12/28/2015 14:58:51
EC Version C 00 B
Processor Information
Name Haswell ULT
Brand String Intel(R) Core(TM) i5-430
Frequency 2600 MHz
Processor ID 40651
Stepping D0
Number of Processors 2Core(s) / 4Thread(s)
Microcode Revision 1c
GT2 (400 MHz)
GT Info
IGFX VBIOS Version 1039
Memory RC Version 1.9.0.0
Total Memory 4096 MB (DDR3)
Memory Frequency 1333 MHz
PCH Information
Name LynxPoint-LP
Version 2.17.1246. Copyright (C) 2015 American Megatrends, Inc.
Copyright © 2017 NEXCOM International Co., Ltd. All Rights Reserved.
Security Save & Exit
▲
Set the Date. Use Tab to
switch between Date elements.
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
▼
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Main Advanced Chipset
Microcode Revision
GT Info
to
IGFX VBIOS Version
Memory RC Version
Total Memory
Memory Frequency
PCH Information
Name
PCH SKU
Stepping
LAN PHY Revision
ME FW Version
ME Firmware SKU
SPI Clock Frequency
DOFR Support
Read Status Clock Frequency
Write Status Clock Frequency
Fast Read Status Clock Frequency
System Date
System Time
Version 2.17.1246. Copyright (C) 2015 American Megatrends, Inc.
System Date
The date format is <day>, <month>, <date>, <year>. Day displays a day,
from Monday to Sunday. Month displays the month, from January to
December. Date displays the date, from 1 to 31. Year displays the year, from
1999 to 2099.
System Time
The time format is <hour>, <minute>, <second>. The time is based on the
24-hour military-time clock. For example, 1 p.m. is 13:00:00. Hour displays
hours from 00 to 23. Minute displays minutes from 00 to 59. Second displays
seconds from 00 to 59.
51
Boot Security Save & Exit
▲
1c Set the Time. Use Tab to
switch between Time elements.
GT2 (400 MHz)
1039
1.9.0.0
4096 MB (DDR3)
1333 MHz
LynxPoint-LP
Premium SKU
04/B2
N/A
9.5.35.1862
→←: Select Screen
1.5MB
↑↓: Select Item
Enter: Select
+/-: Change Opt.
Supported F1: General Help
F2: Previous Values
50 MHz
F3: Optimized Defaults
50 MHz
F4: Save & Exit
50 MHz
ESC: Exit
[Wed 09/06/2017]
[15:50:00]
▼
