Step Motor Controller
Fieldbus Network
EtherCAT/EtherNet/IP™/PROFINET/
®
DeviceNet /IO-Link/CC-Link Direct Input Type
Step Motor Controller/JXC
JXCE1 JXC91
Two types of operation command
Step no. defi ned operation: Operate using the preset
step data in the controller.
Numerical data defi ned operation: The actuator operates
using values such as position and speed from the PLC.
Numerical monitoring available
Numerical information, such as the current speed, current
position, and alarm codes, can be monitored on the PLC.
Application
PLC
Both air and electric systems can be established
under the same protocol.
Electric Actuators
<Applicable Electric Actuators>
High Rigidity and
High Precision Slider Type
LEKFS
Series
Slide Table/High Precision Type
LESYH
Series
3
JXC
Series
JXCP1
Communication protocols
Air Cylinders
EX260
Slider Type Low Profi le Slider Type
LEF LEM
Series Series
Slide Table
LES/LESH
Series
Series
18
p.
JXCD1 JXCL1
Transition wiring of communication cables
Two communication ports are provided.
∗ For the DeviceNet
®
type and CC-Link type, transition wiring is
possible using a branch connector.
∗ 1 to 1 in the case of IO-Link
PLC
Can be additionally installed in
an existing network
IO-Link Communication
IO-Link
master
Guide Rod Slider
LEL
Series
Miniature Type Gripper
LEPY/LEPS LEH
Series
With
STO
sub-
function
JX JXCLF X C C LF JXCM1
Rod Type
LEY/LEYG
Series
Rotary Table
LER
