JXC51/61
How to Mount
a) Screw mounting (JXC 17 - )
(Installation with two M4 screws)
Mounting direction
Mounting direction
∗ When size 25 or more of the LE series are used, the space between the controllers should be 10 mm or more.
DIN rail
AXT100-DR-
∗ For
, enter a number from the No. line in the table below.
Refer to the dimension drawings on page 10 for the mounting dimensions.
L Dimensions [mm]
No.
1
2
3
L
23
35.5
48
No.
21
22
23
L
273
285.5
298
DIN rail mounting adapter
LEC-D0
(with 2 mounting screws)
This should be used when the DIN rail mounting adapter is mounted onto a screw mounting type controller afterward.
9
Series
Ground wire
4
5
6
7
60.5
73
85.5
98
110.5
24
25
26
27
310.5
323
335.5
348
360.5
b) DIN rail mounting (JXC 18 - )
(Installation with the DIN rail)
Ground wire
A
Hook the controller on the DIN rail and press
the lever of section A in the arrow direction to lock it.
8
9
10
11
12
123
135.5
148
160.5
28
29
30
31
32
373
385.5
398
410.5
DIN rail is locked.
DIN rail
DIN rail mounting adapter
L
12.5
5.25
(Pitch)
1.25
13
14
15
16
17
173
185.5
198
210.5
223
33
34
35
36
37
423
435.5
448
460.5
473
Ground
wire
7.5
18
19
20
235.5
248
260.5
38
39
40
485.5
498
510.5
