2.3 Startup Procedures (changed)

Confirmation of the package content
After unpacking everything, check the description on the label to identify the controller and the number of
accessories. If any parts are missing or damaged, please contact your distributor.
Item
Controller (LECP6###-#-XB55)
Power supply plug (LEC-D1-1)
I/O cable (LEC-CN5-#)
*1) Included in the package only when the I/O cable length is
specified.
【Option】
●Teaching box
●Controller setting kit
● Actuator cable
●I/O cable

3. Product Specifications

3.1 Outside dimension diagram

The outside view of this product is as shown in the diagram below:

(1) Screw mount type (LECP6##-#-X120)

Quantity
1 unit
1 piece
*1)
1 piece
Teaching box
- 7 -
Controller
Power supply plug
I/O cable
Controller setting kit
Actuator cable
No.JXC※-OMW1019-A
