Panel View
HE02EXT

LED Instruction

Status Color
LINK GREEN
VIDEO BLUE
FW UP RED
Status Color
ON GREEN
IR RX BLUE
IR TX RED
3
HE02EXR
HE02EXT
ON: HDBaseT Linking
ON: Input signal 4K@60Hz 4:4:4
ON: Firmware Update
HE02EIXT
ON: Power normal
ON: Receiving IR signal
ON: Sending IR signal
User Manual
HE02EX
HE02EXR
HE02EIXR
