- Page 1 HDMI over HDBaseT Extender User Manual Model : HE02EI 4K HDMI & IR CAT5e Extender 70M Smart Cabling & Transmission Corp. V1.0_150429B...
-
Page 2: Installation View
User Manual HE02EI Introduction HE02EI is a 4K HDMI over HDBaseT™ extender that can use an Ethernet cable to send uncompressed HDMI, bi-directional IR signals with resolution up to 4K@60Hz 4:2:0 and transmission distance up to 70M. Features Resolution up to 4K@60Hz 4:2:0. - Page 3 User Manual HE02EI Cable Link cable recommend use high quality CAT.5e、CAT.6、CAT.6a、CAT.7 UTP / STP or FTP cable. Poor quality cable or network connection or improper construction will cause unstable connection, video or sound disruptions, picture noise appears. HDBaseT Distance Chart by Different Cable...
-
Page 4: Package Include
User Manual HE02EI Caution The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone, microwave, radio equipment, fluorescent lamp, high voltage power lines. 2. The cable must pull in straight to avoid any crosstalk interference and the transmission stability. -
Page 5: Specification
User Manual HE02EI Specification ITEM NO. HE02EIT HE02EIR Support Compliance HDMI 1.4, HDCP, 3D Max. Video Resolution 4K@30Hz Max. Transmission Distance 70M at 1080p@60Hz, 40M at 4K@30Hz Video Bandwidth 10.2 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA 30-60Khz, ±...
