Summary of Contents for SC&T HE02P
- Page 1 HDMI over HDBaseT Extender User Manual Model : HE02P 4K HDMI & IR/RS232/Ethernet/PoH CAT5e Extender 100M Smart Cabling & Transmission Corp. V1.0_1507301...
-
Page 2: Installation View
100M. The extender also supports PoH (Power over HDBaseT), designed to provide power from one side (TX/ RX) to another. A built-in Ethernet port with 10/100 bandwidth on both TX and RX sides allows HE02P to connect with standard network devices such as 100Base-T routers, hubs, and computers. - Page 3 User Manual HE02P HDBaseT Distance chart by different cable Cable Type Range Pixel Clock Rate Video Data Rate Supported Video <=5.3Gbps Up to 100m <=225Mhz (HD Video) 1080p 60Hz 36 bits CAT5e / CAT6 1080p 60Hz 48bits, >5.3Gbps >225Mhz 1080p 60Hz 3D,...
-
Page 4: Low Power Mode
User Manual HE02P HDBaseT Port Status LED Color LED Function HE02PT HE02PR Green HDBaseT Linking On: HDBaseT Linking , Flash: Low Power Mode Blue Reserve No Function HDMI On: With HDCP , Flash: Without HDCP , Off: HDMI Unlink 10/100 Ethernet Port... -
Page 5: Package Include
User Manual HE02P Package Include Transmitter x 1 piece Receiver x 1 piece Power adapter DC24V 1AMP x 1 piece IR Emitter cable x 2 pieces IR Receiver cable x 2 pieces... -
Page 6: Specification
User Manual HE02P Specification ITEM NO. HE02PT HE02PR Support Compliance HDMI 1.4, HDCP, DVI Max. Video Resolution 4K@30Hz 4:4:4 Max. Transmission Distance 100M over CAT6 or greater cable Video Bandwidth 10.2 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA...
