- Page 1 HDMI over HDBaseT Extender User Manual Model : HE02N 4K HDMI & IR/RS232/Ethernet/ARC CAT5e Extender 100M Smart Cabling & Transmission Corp. V1.0_1507301...
-
Page 2: Installation View
TV and the amplifier. And a built-in Ethernet port with 10/100 bandwidth on both TX and RX sides allows the HE02N to connect with standard network devices such as 100Base-T routers, TVs, and computers. - Page 3 User Manual HE02N HDBaseT Distance chart by different cable Cable Type Range Pixel Clock Rate Video Data Rate Supported Video <=5.3Gbps Up to 100m <=225Mhz (HD Video) 1080p 60Hz 36 bits CAT5e / CAT6 1080p 60Hz 48bits >5.3Gbps >225Mhz 1080p 60Hz 3D,...
-
Page 4: Panel View
User Manual HE02N HDMI On: with HDCP, Dark: HDMI Unlink 10/100 Ethernet Port: Color LED Function HE02NT HE02NR GREEN Ethernet linking On: Linking, Flash: data transmission YELLOW No function Digital Audio Return This product supports the TV audio sent from HDMI ARC (Audio Return Channel) or Digital optical audio mode, from the receiver back to the transmitter end. -
Page 5: Package Include
User Manual HE02N Package Include HE02NT Transmitter x 1 piece HE02NR Receiver x 1 piece Power adapter x 2 piece Mounting screw pack x 2 bags IR Emitter cable x 2 pieces IR Receiver cable x 2 pieces... -
Page 6: Specification
User Manual HE02N Specification ITEM NO. HE02NT HE02NR Support Compliance HDMI 1.4, HDCP, DVI Max. Video Resolution 4K@30Hz 4:4:4 Max. Transmission Distance 100M over CAT6 or greater cable Video Bandwidth 10.2 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA...
