SC&T HE02EIP User Manual

Hdmi over hdbaset extender 4k hdmi & ir/poh cat5e extender 70m

Advertisement

Quick Links

HDMI over HDBaseT Extender
User Manual
Model :
HE02EIP
4K HDMI & IR/PoH CAT5e Extender 70M
Smart Cabling & Transmission Corp.
V1.0_150819M

Advertisement

loading
Need help?

Need help?

Do you have a question about the HE02EIP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SC&T HE02EIP

  • Page 1 HDMI over HDBaseT Extender User Manual Model : HE02EIP 4K HDMI & IR/PoH CAT5e Extender 70M Smart Cabling & Transmission Corp. V1.0_150819M...
  • Page 2: Installation View

    HE02EIP Introduction HE02EIP is a 4K HDMI over HDBaseT™ extender that can use an Ethernet cable to send uncompressed HDMI and IR signals with resolution up to 4K@60Hz 4:2:0 and transmission distance up to 70M. The extender also supports PoH (Power over HDBaseT), designed to provide power from one side (TX/ RX) to another.
  • Page 3: Low Power Mode

    User Manual HE02EIP Cable Link cable recommend use high quality Cat.5e、Cat.6、Cat.6a、Cat.7 UTP / STP or FTP cable. Poor quality cable or network connection or improper construction will cause unstable connection, video or sound disruptions, picture noise appears. HDBaseT Distance Chart by Different Cable...
  • Page 4 4. IR transmitter do not put near from receiver to avoid mutual interference. 5. The receiver unit working temperature is higher which is in normal condition. HE02EIP Package Include HE02EIPT HDM Transmitter x 1 pcs HE02EIPR HDMI Receiver x 1 pcs...
  • Page 5: Specification

    User Manual HE02EIP Specification ITEM NO. HE02EIPT HE02EIPR Support Compliance HDMI 1.4, HDCP, 3D Max. Video Resolution 4K@24Hz Max. Transmission Distance 70M at 1080p, 40M at 4K Video Bandwidth 10.2 Gbps Audio Format LPCM 7.1 192KHz, Dolby Trued, DTS-HD MA IR Support 30-60Khz, ±15°, 5M, Bi-directional...
