SC&T HE02EX User Manual page 3

HDBaseT Distance Chart by Different Cable
Cable Type
CAT5e / CAT6
CAT6a / CAT7
CAT5e / CAT6
CAT6a / CAT7
If connection through the wall socket, the cable length must less 5 meters between HDMI extender
and wall jack, as below drawing
HE02EXT
5M MAX
RJ45 Define
Video Link (TIA/EIA-568-B)
1. Orange-white DATA0 +
2. Orange DATA0 -
3. Green-white DATA1 +
4. Blue DATA2 +
5. Blue-white DATA2 -
6. Green DATA1 -
7. Brown-white DATA3 +
8. Brown DATA3 -
Range
100m
100m
70m
100m
Wall Jack
Supported Video
Up to
1080p 60Hz 12bit
Up to 4096x2160@60Hz 4:4:4
MAX 70M
User Manual
HE02EXR
Wall Jack
5M MAX.
HE02EX
2
