- Page 1 HDMI over HDBaseT Extender User Manual Model : HE02EX 4K 60Hz 4:4:4 HDMI & IR/R232 CAT5e Extender 100M Smart Cabling & Transmission Corp. V1.0_1901311...
-
Page 2: Installation View
HE02EX Introduction HE02EX is a 4K HDMI over HDBaseT™ extender that can use an Ethernet cable to send uncompressed HDMI, bi-directional IR and RS232 signals with resolution up to 4K@60Hz 4:4:4 and transmission distance up to 100M. Its TX unit has a built-in local loop out port that can connect with an extra HDMI display and its RX unit has dual HDMI outputs for signal distribution. - Page 3 User Manual HE02EX HDBaseT Distance Chart by Different Cable Cable Type Range Supported Video CAT5e / CAT6 100m Up to 1080p 60Hz 12bit CAT6a / CAT7 100m CAT5e / CAT6 Up to 4096x2160@60Hz 4:4:4 CAT6a / CAT7 100m If connection through the wall socket, the cable length must less 5 meters between HDMI extender...
-
Page 4: Led Instruction
User Manual HE02EX Panel View HE02EXT HE02EXR LED Instruction Status Color HE02EXT HE02EXR LINK GREEN ON: HDBaseT Linking VIDEO BLUE ON: Input signal 4K@60Hz 4:4:4 FW UP ON: Firmware Update Status Color HE02EIXT HE02EIXR GREEN ON: Power normal IR RX... -
Page 5: Package Include
User Manual HE02EX Firmware updated Switch 1 2 3 4 1. RS232 ON: Firmware Update, OFF: RS232 Extender 2. Reserve Must Keep Off 3. Low Power Mode ON: Turn off power saving mode, OFF: Turn on power saving mode 4. Reserve... -
Page 6: Troubleshooting
User Manual HE02EX Trouble Shooting 1. The wiring must away from any equipment with electromagnetic wave, i.e.: mobile phone, microwave, radio equipment, fluorescent lamp, high voltage power lines. 2 Under HDMI 2.0 mode, must use Premium certified HDMI cable. 3 EDID pass through for HE02EXT transmitter input and HE02EXR receiver output 1 only. -
Page 7: Specification
User Manual HE02EX Specification ITEM NO. HE02EXT HE02EXR Support Compliance HDMI 2.0, HDCP 2.2, 1.4, DVI Max. Video Resolution 4K@60Hz 4:4:4 Max. Transmission Distance 100M over CAT6 or greater cable Video Bandwidth 18 Gbps Audio Format 7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA IR Support 30-60Khz, ±15°, 5M, Bi-directional 30-60Khz, ±55°, 5M, Bi-directional...
