Always place the charger in stable and safe position.

During charging, do not touch the metallic casing of the charger, to avoid high-temperature

scalding.

3.1.3 Base station charging

When using it for the first time, be sure to fully charge the battery. Please use dedicated charger to
charge the base station.
1. Plug the Type-C power cord into the Type-C port of the base station. The base station will
automatically enter into the charging mode (either when it is turned on or off).
2. During charging, the base station power indicator will flash, and the battery level will be
indicated by different colors. When connected to the charging power supply, the base station
power indicator is normally on green, indicating that it is fully charged.
Green
Yellow
Red
Red and slow flash

3.2 Ground station preparation

3.2.1 Extend ground station

The ground station is folded in the packing box. Please carefully extend the antenna before use to
prevent damage and ensure the best flight range.
Antenna position adjustment

Keep the two antennas upright and parallel to each other to obtain best signals, as shown in the
figure below.
Battery level ＞60%
Battery level ＞30%
Battery level ＞10%
Battery level ＜10%
24
