- Page 1 EVO Max 4T Maintenance Manual March 2023...
-
Page 2: Table Of Contents
Contents Introduction And Overview Usage Agreement Safe Flight Guidelines Flight Condition Requirements Operational Requirements Flight Restriction Transportation Guidelines Firmware Upgrade Maintenance And Checks Pre-flight Checks Maintenance And Checks Component Inspection Powersystem Flight Control System Fuselage Battery Upgrades And Calibration Consumable Parts List After-Sales Service Warranty Policy Warranty Period For Main Components（12-month guarantee on whole product）... -
Page 3: Introduction And Overview
Upon using this product, you are deemed to have read this document carefully, understood and accepted all the terms and contents of this document and all related documents of this product. Autel Robotics are not responsible for any damage and any legal responsibility caused by the direct or indirect use of this product. -
Page 4: Transportation Guidelines
The batteries of the remote controller and the aircraft are fully charged, and the batteries must be installed in place without detaching; Make sure that the propeller is an authentic Autel Robotics supplied propeller, the appearance is intact, it is installed firmly, the front and back propellers are both installed correctly, there is no foreign matter or debris in the motor and propeller, and there is no blockage in the manual rotation of the motor;... -
Page 5: Maintenance And Checks
*Time stated (every year or every 3 years) is noted as the time since activation. For different regions, Autel Robotics may adjust the maintenance type and cycle. For the latest service details, please consult your local dealer or Autel Robotics After-Sales team... - Page 6 *It is recommended to replace the propeller blades only in emergency situations in field operations; after any emergency flight, please contact the official technical support or authorized agent of Autel Robotics for maintenance guides promptly.
-
Page 7: Flight Control System
Flight Control System The "Visual Positioning Mode" will appear after turning on the aircraft. Please observe the surrounding environment and place the aircraft in an open and unobstructed environment to search for satellites. If the number of searched satellites is more than 28, this is good and within the recommended range. - Page 8 Check all screws of the fuselage and make sure there are no loose screws or any missing screws. Screws Check all for any loosening screws; Check for any damage or cracks on the conjunction between the arm and fuselage； Folding Arms When the arm is unfolded, check to see if there is any obvious gap between the arm and fuselage；...
- Page 9 buckles should push back normally without obvious shaking. Wipe off any foreign debris near the interface; Check the interface to see whether there is any foreign matters; Use tweezers to remove any debris in the interface, such as small stones and Data Interface small pieces of paper;...
-
Page 10: Battery
Double check if the dampeners are damaged, loose, aged, softened or Dampeners stretched; Check whether the screws on the connecting plate are loose. Move the tilt axis of the gimbal up to 90°, and check whether the camera can Gimbal be locked normally;... - Page 11 The battery has been cycled 50 times. The battery has been inactive for 3 months. The App prompts users that the battery needs maintenance. Battery Inspection Process 1. The battery performs a standard charge and discharge operation. 2. Insert the battery into the aircraft and power on, check the battery information through the app, check whether the voltage difference between the battery cells is less than 0.1V, and whether the battery firmware is up to date.
-
Page 12: Upgrades And Calibration
Update And Calibration Please update the firmware of the aircraft and remote controller regularly, and perform regular calibrations. Classification Aircraft Firmware Upgrade Remote Controller Firmware Upgrade IMU Calibration Compass Calibration Vision System Calibration Gimbal Calibration Wearing Parts List Replace damaged and consumed parts promptly to keep the aircraft in the best possible condition and reduce any potential safety hazards. -
Page 13: After-Sales Service
Connect the remote controller to the computer, export flight control data and flight records, and contact Autel Robotics Technical Support or your local agent for data analysis; Autel Robotics will give a solution based on the analysis results. -
Page 14: Shipping Channels
Connect the remote controller to the computer, export flight control data and flight records, and contact Autel Robotics Technical Support or your local agent for data analysis; Please send the device back for repair.
