6. Install intelligent aircraft battery
When the aircraft battery is installed or removed, be sure to turn off the aircraft power. Align the
battery port with the battery port on the fuselage, put in the battery until you hear a click.

3.4.2 Activate aircraft

1. Turn on the ground station power supply
Press and hold the power supply button for 1s to turn on the ground station power supply.
2. Turn on the base station power supply
Press and hold the power supply button for 1s to turn on the base station.
3. Turn on the aircraft power supply
Press and hold the fuselage power supply button for 3s to turn on the aircraft power supply
30
