Configuring the Micro800 Expansion I/O 2085-OX32-SC Using CCW
Chapter 3:

PLC Interfaces

Parameter
Vendor ID
Product Type
Product Code
Series Rev
Module Catalog String
Table
Configuration
Input
Output
CCW Var Index Bit
_IO_Xx_ST_32 0
_IO_Xx_ST_33
1
_IO_Xx_ST_39:34 7:2
The 2085 platform stores the following values in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
OV32-SC
58 (Spectrum Controls)
7 (Discrete)
116
A
2085-OV32-SC

3.5.1 Connection Types and Assembly Sizes

The size of each assembly is listed in the table below. Each word takes 2 bytes:
Size (words) Notes
0 Module does not require a configuration
3
2

3.5.2 Output Variable Table

The read-only status variable is located on the CCW Global Variables tab in
visual checkbox format, and in _IO_Xx_ST_yy string format, where:
x represents the expansion slot number 1...3 for the Micro850 controller
•
and slot number 1...8 for the Micro870 controller
yy represents the generic number from 00 to 47.
•
Channel Status (CCW Var: _IO_Xx_ST_31:00)
Channel status variable is a replica of the reading from FPGA responses.
Whenever any channel control is enabled by the user during RUN mode, the
corresponding channel status variable is also checked as enabled.
Module Status (CCW Var: _IO_Xx_ST_47:32)
The module status variables used in this range are reserved for indicating
different module behaviors as listed below:
Name Description
FPGA Fault
FPGA
When enabled, indicates there is a module communication
failure over to the FPGA chip. This is a hardware fault.
Module Power Brownout
BO
When enabled, indicates there is a power supply failure to the
module microprocessor and FPGA. This is a hardware fault.
Not Used Variables marked as Not Used remain disabled.
OB32-SC
58 (Spectrum Controls)
7 (Discrete)
115
A
2085-OB32-SC
