System
Introduction
Chapter 3
Configuring the 2085-OX32-SC
Using CCW
This chapter covers the following subjects:
How to use Connected Components Workbench (CCW) and, optionally,
ModuleConfigConverter.exe software to configure the Module.
Analog Data and Status settings.
Data Links settings.
Setting configuration parameters and associated values.
You use CCW software (v 9.00.00 and above) to configure the 2085-OX32-SC
Expansion I/O Modules. Your controller firmware must be at v. 9.011 and above
as well. Starting from CCW version 11.00.00 and later, the software provides a
module-specific Add-On Profile (AOP) to operate the module. The process for
manually importing AOP to CCW is no longer required.
The Micro800 Controller (Bus master) subsystem is located at the left end of the
bus. This subsystem is comprised of:
Micro800 Controller.
Micro800 Expansion I/O Modules.
2085-ECR Bus Terminator.
Optional:
2080-PS120-240VAC Power Supply (separate module or built-in the main
controller).
2080 Expansion Modules.
2085-EP24VDC Expansion Power Supply for Micro870 Controller with
more than four Micro800 Expansion I/O Modules installed.
User's Manual Pub. 0300309-01 Rev. B
