Environmental Tests
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
AC Mains Voltage Dips,
Interruptions and Variations
Safety Tests
UL Safety
UL Hazardous
Locations
CE EMC Directive
UKCA
FCC
ROROC
Hardware Features
Test Level Limits
Signal Ports:
± 2 kV line-earth {CM} at 42 Ω
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
10 V RMS with 1 kHz sine wave 80% AM from 150
kHz...80 MHz on signal and power ports
30 Arms/m
Follow the 61000-4-11.
Table 1-3. Safety Test Specification Table
Industry Standards
UL 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 2-201: Particular
Requirements for Control Equipment (NRAQ, NRAQ7)
CAN/CSA C22.2 No. 61010-1-12 (Safety Requirements for Electrical
Equipment for Measurement, Control,
and Laboratory Use – Part 1: General Requirements)
ANSI/ISA–12.12.01 Nonincendive Electrical Equipment for Use in Class I,
Division 2 Hazardous (Classified) Locations (NRAG)
CSA C22.2 No. 213-M1987 - Non-incendive Electrical Equipment for use in
Class I Division 2 Hazardous Locations - March 1987 (NRAG7)
Temp code T4 or better, Pollution degree 2, gas groups a,b,c, & d
EN 61131-2 Programmable Controllers: Third Edition 2007-02, Clause 8,
Zones A&B
EN 61000-6-2: Generic Industrial Immunity
EN 61000-6-4: Generic Industrial Emissions
Electromagnetic Compatibility Regulations 2016
BS EN 61131-2, BS EN 61000-6-4, BS EN 61000-6-2
27 CFR Part 15, Class A
Arrêté ministériel n° 6404-15 du 29 ramadan 1436 (16 juillet 2015)
NM EN 61131-2, NM EN 61000-6-4, NM EN 61000-6-2
Channels are all outputs. To actively control the state of the outputs, you must set
up a program within the PLC and transition the Controller to Run mode.
Chapter 1: Module Overview
User's Manual Pub. 0300309-01 Rev. B
1-5
