Table 1-1. Output/Performance/Environmental Requirements
Output Description
Operating Temperature
Storage/Non-Operating
Temperature
Operating Humidity
Storage/Non-Operating Humidity
Vibration/Operating
Operating Shock
Storage/Non-Operating Shock
Pollution Level
Outputs per module
12/24 VDC customer supply
voltage
ON-state voltage
ON-State Voltage Drop
ON-state current
Off-state leakage current
Turn on/off time, maximum
(backplane to screw)
Surge current
Reverse voltage protection
Inductive kickback protection
Output to backplane isolation
Group-to-Group isolation
Output to Chasis GND isolation
Power Requirements
Bus +5 VDC (4.75 V to 5.4 V)
Bus +24 VDC (19.9 V to 26.4 V)
Chapter 1: Module Overview
Value
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
5% to 95%, non-condensing
5% to 85%, non-condensing
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
25 G, peak acceleration, 11 ms pulse, half sine
25 G peak acceleration, (35 G for panel mount), 11 ms pulse,
half sine
Meets Pollution Degree 2 requirements.
32
10.5 VDC minimum, 30 VDC maximum
10 VDC minimum ON under all conditions
24 VDC nominal under all conditions
30 VDC maximum
Less than 0.5 VDC maximum
1 mA minimum at 10 VDC
0.5 A maximum steady state (8 A per channel group)
Less than 0.5 mA per channel.
3 ms
2 A for 25 ms, repeatable every 2 seconds
10 A maximum per channel group
Yes, group protection
Yes. Diode across load to protect against load coil back EMF.
50 VAC working Reinforced isolation tested at 2 kVDC for 1
minute
50 VAC working Basic isolation tested at 1300 VDC for 1
minute.
50 V working Reinforced isolation tested at 2 kVDC for 1
minute.
70 mA maximum
55 mA maximum
